Product Overview
Designed for daily routines, the 2pcs 5V Micro USB Timer Relay DC 6-30V Programmable Cycle Delay Timer Switch Module with Digital LED Display combines adjustable construction with reliable performance. Engineered using Silver Alloy. Notable features include product parameters and parameters operating, contributing to its reliable character.
Key Features
- 【Product Parameters】Operating voltage: DC 6V-30V, support micro USB 5V power supply; trigger source: high level (3V-24V), with optocoupler isolation; output power: 30V/5A DC,220V/5A AC; quiescent current: 20mA; operating current: 50mA; operating temperature: -40℃-85℃(-40℉-185℉).
- 【Timing Range】The time delay relay supports 0.1 seconds (min) - 999 minutes (max) continuously adjustable. The timing range is selected by short pressing the STOP button after setting the parameter values in the mode selection interface.
- 【Enable Mode】 ON: the delay relay is allowed to be on during the OP conduction time; OFF: the delay relay is forbidden to be on and is off; short press the STOP button in the main interface to switch between ON and OFF, the current state will flash and then return to the main interface.
- 【Sleep Mode】 When the digital LED cycling relay is enabled,digital tube of the relay board will automatically turn off if there is no operation for 5 minutes. It can be woken up by pressing any of the buttons.
- 【Application Scenario】DC 6-30V programmable delay relay is widely used in electronic security systems, industrial automation equipment, intelligent irrigation systems and home automation systems, etc.
Why Choose the FORIOT 2pcs 5V Micro USB Timer Relay DC 6-30V Programmable Cycle Delay Timer Switch Module with Digital LED Display
The 2pcs 5V Micro USB Timer Relay DC 6-30V Programmable Cycle Delay Timer Switch Module with Digital LED Display demonstrates thoughtfully designed engineering with practical features like product parameters, leading to thoughtful design that holds up over time.
Best For
Anyone focused on daily routines should consider the 2pcs 5V Micro USB Timer Relay DC 6-30V Programmable Cycle Delay Timer Switch Module with Digital LED Display for its reliable performance and thoughtfully designed design.
Quick Summary
The FORIOT 2pcs 5V Micro USB Timer Relay DC 6-30V Programmable Cycle Delay Timer Switch Module with Digital LED Display is a Timers product by FORIOT. Connector Type: Usb. Contact Material: Silver Alloy. Contact Type: Normally Open. Current Rating: 5 Amps. Mounting Type: DIN Rail Mount. Price: $14.38.
Product Specifications
| Specification | Details |
|---|---|
| Connector Type | Usb |
| Contact Material | Silver Alloy |
| Contact Type | Normally Open |
| Current Rating | 5 Amps |
| Mounting Type | DIN Rail Mount |
