2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer by Coliao

2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer

$17.98
Skip to product information
2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer by Coliao
1/7
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer by Coliao
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 2
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 3
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 4
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 5
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 6
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 7
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer by Coliao
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 2
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 3
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 4
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 5
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 6
  • 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer - Image 7
2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer

2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer

$17.98
Shipping calculated at checkout.
Description

Product Overview

From the materials to the finish, the 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer with LED Display Support Micro USB 5V Power Supply, Smart Home Controller reflects adjustable choices that support practical use in household use. Made with Gold. Notable features include dc 6-30v and 6-30v timer, contributing to its well-made character.

Key Features

  • 【DC 6-30V Timer Relay】Multifunction timer relay widely used at smart home, industrial control, automatic irrigation, indoor ventilation, protection equipment,etc.
  • 【Timer Relay Parameter】Operating Voltage: DC 6-30V, support micro USB 5V power supply; Operating Current: 50mA; Static Current: 20mA; High level trigger: 3V - 24V. NO(Normally open) maximum load < AC 250V/10A, < DC 30V/10A. Timing range: 0.1s ~ 999mins (continuously adjustable).
  • 【Parameter Setting】OP(conduction time) / CL(off time) / LOP(circuit times) can be set individually, and the parameters are mutually independent. All parameters are permanently saved once set. The functions and parameters can be reviewed or changed at a later time.
  • 【Sleep Mode】1. "C-P" Sleep mode: if no operation within 5 minutes, the digital display automatically turns off, the program runs as usual; 2. "O-d" Normal mode: digital display turns on all the time; Press and hold the "STOP" button for two seconds to switch "C-P" and "O-d" state, the current state flashes and then return to the main interface.
  • 【Reverse Protection】Built-in a diode to provide protection against accidental reverse polarity for the circuits, and set a button emergency stop function (STOP button).

Why Choose the Coliao 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer with LED Display Support Micro USB 5V Power Supply

The 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer with LED Display Support Micro USB 5V Power Supply, Smart Home Controller brings together user-tested and time-tested qualities, plus dc 6-30v, to deliver everyday convenience in electromechanical relays settings.

Best For

The 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer with LED Display Support Micro USB 5V Power Supply, Smart Home Controller pairs naturally with household use situations, offering practical use when it counts.

Quick Summary

The Coliao 2pcs DC 6-30V Timer Relay Programmable Time Delay Relay Module Cycle Timer with LED Display Support Micro USB 5V Power Supply is a Electromechanical Relays product by Coliao. Connector Type: Usb. Contact Material: Gold. Contact Type: 2no 2nc. Current Rating: 50 Milliamps. Mounting Type: PCB Mount. Price: $17.98.

Product Specifications

Specification Details
Connector Type Usb
Contact Material Gold
Contact Type 2no 2nc
Current Rating 50 Milliamps
Mounting Type PCB Mount
